On-land power
Inboard Petrol engine, Honda - 22HP (16kW) 4-stroke, air cooled

Top speed (Land)
7.5kph (5mph)

Run Time (Land)
30 min continuous run time per hour with warning alarms

Drive (Land)
All wheel drive, Permanent with momentary diff lock

Brakes
Primary/Dynamic – Hydrostatic Emergency/Automatic Park – Hydraulically released mechanical brake

Tyres
25”x 12” all terrain 6-ply tyres on 12” alloy rims

Maximum incline (Land)
14 Degrees (25% grade) up. 11 Degrees (20% grade) down. Avoid driving across a transverse incline.

Recommended & Max Outboard
1x 115HP (86 kW)

Top speed Max (Water)
35 knots (65kph/40 mph)

Fuel Capacity – Petrol
Below deck 80 litre (21 U.S. Gallons)

Displacement – no fuel
1350kg (2976lbs)

Steering
Seastar power assisted hydraulic steering

Maximum sea conditions
Up to 2.0m (6’ 7”) wave height
Up to 26 knot (49kph/30 mph) winds

Length Overall (wheels up)
6.13m (20’ 1”)

Hull Length Overall (not incl. wheels)
4.91m (16’ 1”)

Height
2.35m (7’ 8”) [Wheels Down],
1.82m (6’) [Wheels Up]

Beam overall
2.46m (8’ 1”)

Draft (Outboard trimmed up)
0.41m (16”)

Hull Deadrise at transom
21 degrees

Seating
Twin driver seat, single bow seat, single console seat Optional twin driver backrest, twin transom seat, transom hand-hold

Storage
Under-seat in front of console, 2x wet floor lockers, transom locker

Console
Centre console with fold down windscreen, 2x cup holders

Deck
Anti-slip deck tread

Batteries
High Crank Start Battery (750CCA)
Optional second battery (90AH House)

Drainage and bilge
Dual scuppers, 1100gph (4164Lph) automatic and switchable bilge pump

Lighting
Bow-mounted LED marine headlight (land use only), LED navigation lights

Outboard Options

• Yamaha 115
• Yamaha Helm Master Level 3

Seating

• Helm Seat Backrest
• Transom Seat

Personalisation

• Paint Upgrades - Standard Upgrade

Electrical

• Simrad GPS/ Chartplotter NSS9
• Simrad GPS/ Chartplotter NSS12
• Chartplotter Upgrades - Outboard Interface
• Chartplotter Upgrades - Active Imaging Transducer
• Chartplotter Upgrades - Simrad 3D Structurescan transducer
• Fusion Stereo Head Unit, 2 x 6" Speakers
• Fusion Stereo Head Unit, 4 x 6.5" Signature Speakers
• Fusion Apollo Series Head Unit 6 x 6.5" Signature Speakers, Amp, Sub
• Simrad VHF
• Battery Charger 10 amp
• Dual Battery System
• Drum Winch - with bowsprit
• 12V Tube Inflation Pump
• Variable Direction Floodlights (Pair)
• Bow Camera
• Saltwater Washdown Pump

Accessories

• RIB Boarding Ladder
• All-Wheel Differential Lock & High Speed Drive
• Anchor with chain and 50m rope
• Bait Board
• Folding Bowsprit
• Lifejacket, Sealegs Black
• Maxtrax
• Outboard Hydrofoil
• Tie Down Points
• Railblaza Mounts - Mobile Device Holder

Covers

• T-Top Sport Console
• Folding Bimini
• Centre Console Cover
• RIB Tube Fishing Covers
• 6.5m Craft Storage Cover

Commercial Options

• Transom Bollards
• Hypalon Tube Upgrade to Orca 866
• Rub Strip 2nd Layer
• Rescue Stretcher System

Trailers

• Trailer - 6.5m
